VALUE LINE PRO

SELF-SERVE CAR WASH EQUIPMENT

Hydro-Spray's Value Line Pro Self-Serve Car Wash System offers unparalleled performance and efficiency. This tankless One-Bay, One-Pump self serve car wash system is easy to use, easy to install, and easy to repair. The plug-and-play design was designed by car wash operators for car wash operators and is proven to increase your wash counts.

VALUE LINE PRO WITH STATUS INDICATOR FACE
VALUE LINE PRO SELF- SERVE CAR WASH SYSTEM
Hydro-Spray water spraying icon

VFD MULTI PRESSURE PUMP STAND

Save energy and reduce operating costs with our Value Line Pro. When you need self-serve car wash equipment with custom high, medium and low pressure settings...this is the industry standard. The VFD motor ensures each product is delivered at an optimal pressure setting. The VFD control box runs the electric motor at variable RPMs to efficiently deliver your presoak and bug cleaner. Status indicators on the face help you diagnose and solve issues quickly, saving you time and getting your wash running smoothly again...which saves you money.

DOWNLOAD BROCHURE

  • SPECIFICATIONS

    Specifications:

    4 GPM Pump, 5HP Motor

    24vac Relay Controlled

    Variable Frequency Drive

    230V/3PH/60Hz/13.6A

    Dimensions: 18” x 28” x 60” (W x D x H)


    Requirements:

    20 Amp 3-Phase Circuit Breaker

    Fresh Water Inlet ¾” Hose Barb Gravity Supply Tank

    HP Soap Inlet ¾” Hose Barb Gravity Supply Tank

    HP Wax Inlet ¾” Hose Barb Gravity Supply Tank

    Pre-Soak Inlet ½” Hose Barb Gravity Supply Tank

    Wheel & Tire Inlet ½” Hose Barb Gravity Supply Tank

    Spot Free Water Inlet ¾” Hose Barb Gravity Supply Tank

    Option 1 Inlet ½” Hose Barb Gravity Supply Tank

    Air Supply Inlet ⅜” OD Polyflow @ 5.7


    Outlet Connections:

    Multi Pressure Outlet ⅜” FNPT

    Air Assist Outlet ⅜” OD Polyflow


    Max Water Supply Temp:

    110 F (Recommended)

    Max Water Temp 130 F


    Operating Water Pressure:

    150 PSI to 1500 PSI


    Water Filtration:

    50 Micron


  • FEATURES

    Features:

    Service Friendly/Install Friendly Design

    5HP 3-Phase HD Inverter Rated Electric Motor

    General Platinum Series Pump

    Plug & Play Design

    Direct Drive Pump & Motor

    Heavy Duty Stainless Steel Frame

    Adjustable Legs for Leveling

    VFD Driven

    Bay Lock Out (Enable/Disable Feature)

    Bay Wash Down (Enable/Disable Feature)

    One Bay, One Pump Design

    Multi Pressure Applications

    Rinse

    HP Soap

    HP Wax

    Pre-Soak

    Wheel & Tire Cleaner

    Spot Free Rinse

    Optional Application

    Pressure Regulator

    Pulsation Dampener

    Resettable Maintenance Timer

    Resettable Wash Counter

    Pressure Gauge

    Pre-Wired Terminal Strip

    Weep Saver Valve

    LED Cycle Indicator Lights


  • OPTIONS

    Options:

    CAT Pump

    Wall Mount Rinse Tank Assembly

    Wall Mount Chemical Tank Assemblies

    Free Standing Tank Assembly

    Inlet Water Supply Regulators

    Soft Hose Plumbing Kit

    Multi Pressure Check Valve Assembly

    Caster Kit

    Spare Parts Kit

    Install Kit


  • ACCESSORIES

    Accessories:

    Ceiling Mount  Booms

    Ceiling Mount  Boom Packages

    Meter Boxes

    Full Color Bay Signage

    Wall Mount Mat Clamps

    Undercarriage Cleaning Tool

    Reverse Osmosis Systems (Spot Free Rinse)

    Water Softeners

    Tankless Water Heaters

    Air Compressors

    Change Machines

    Vending Machines


VALUE LINE PRO FEATURES:

● 7 INLET FUNCTIONS
● VARIABLE PRESSURE SETTINGS
● WEEP WATER SAVER
●PRE WIRED WASH DOWN FEATURE
● PRE WIRED IN/OUT SERVICE
● HOUR METER
● RELAY CONTROL WITH PURGE TIMERS
● PRE WIRED ENCLOSURE
● PRE PLUMBED
● STAINLESS STEEL LEVELING FRAME
